DATALOGIC Gryphon GFS-4520 Fixed 2D Scanner USB

(Product may vary from image. Rely only on description for purchasing decisions.)
  • DLGFS4520-U
  • GFS4520-BKK1-RED
  • DATALOGIC
  • GFS4520
    • Login to view pricing and availability

Gryphon I GFS4520, Kit, 2D, MP, Red illumination, 5V, USB-only, microUSB connector, Black (Kit includes Scanner and USB Cable)

Private Products

Warranty specified is Back to Base (BTB) warranty Goodson Imports P/L.
Warranty commencement date is date of hardware Invoice.
Warranty covers Manufacturers Faulty Workmanship
12 Months on Print Head
2 Months on Touch Screen
Warranty excludes:

  • Power supply
  • Interface and Power Cables
  • Consumable products
  • Options
  • Software and Data Recovery
60 months
  • Compact dimensions for easy installation
  • Wide angle 1 MP optics for superior scanning and Depth of Field
  • Advanced motion tolerance optics for first pass reading of any moving barcode
  • Automatic sensing, software, external, manual trigger options available
  • Datalogic distinctive red or white illumination technology with adjustable brightness
  • Intuitive Blue Dot LED aimer for easier targeted scanning
  • Superior good-read feedback (‘Green Spot’ technology, high visibility topfront LED and integrated beeper with adjustable intensity)
  • Omnidirectional reading of 1D, 2D and postal codes plus stacked, composite codes and dot codes; Digital Watermarks on red illumination models
  • Image capture and document scanning capabilities
  • USB, RS-232, USB/RS-232 communication options
  • Water and Particulate Sealing Rating: IP54
  • Disinfectant-Ready enclosure
  • EASEOFCARE Service Plans offer a wide range of service options to protect your investment, ensuring maximum productivity and ROI.
NameSizeDownload
Brochure434kb gryphon4500_Fixed_brochre.pdf

Products available to purchase

All Vendor Sku's for this Products

This product is equivalent to the following products

SKUDescription
GFS4470GFS-4400 2D Imager Fixed Mount Presentation Scanner

Parts documents

Parts layout details

Specifications
Scan Engine
Area Imager
Light Source
Illumination: Red LED 617nm (GFX45XX-RED models)
Warm white LED (GFX45XX-WHT models)
Aiming: Blue LED’s 470 nm
Scan Pattern
1280 x 800 Pixels
Scan Rate
60 full-frame/s
Motion Tolerance
70 IPS (EAN/UPC)
Image Capture
Graphic Formats: BMP, JPEG, TIFF
GreyScale: 256, 16, 2, JPEG, TIFF
Capture Area
Field of View: 51° H x 32° V
Contrast Ratio
15% Minimum reflective difference
Resolution
1D Linear Max. 0.076mm / 3 mils
Datamatrix 0.13mm / 5 mils
PDF417 0.13 / 5 mils
Depth of field
Minimum distance determined by symbol length and scan angle. Printing resolution, contrast, and ambient light dependent.
Code 39: 5 mil: 4 to 30.0 cm
Code 39: 10 mil: 1.7 to 53.5 cm
Data Matrix: 10 mil: 3.5 to 23.5 cm
Data Matrix: 15 mil: 3.0 to 35.0 cm
EAN/UPC: 13 mil: 4.0 to 82.0 cm
PDF417: 10 mil: 1.5 to 35.0 cm
QR Code: 10 mil: 3.5 to 22.0 cm
Tilt Angle
+/-180°
Pitch Angle
+/- 60°
Skew Angle
+/- 60°
Ambient Light Immunity
0 - 120,000 Lux
Symbologies supported
1D:Auto-discriminates all standard 1D codes including GS1 DataBar™ linear codes

2D:Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code; Dot Code; Dot Matrix
Postal Codes: Australian Post; British Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Postnet; Royal Mail Code (RM4SCC)

Stacked Codes: EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites

Digital Watermarking: Digimarc Barcodes
Programming Method
Manual: Reads special bar codes
Automatic: Software commands through the RS-232 / USB interfaces
Datalogic Aladdin™: Windows configuration program
Remote Host Download (Lowers service costs and improves operations)
Driver available
JavaPOS, OPOS Utilities
Indicators/Controls
Scanner Indicators:
Top Front Good Read LED (Adjustable brightness)
Good Read LED "Green spot" on the code
Adjustable Tone & Volume beeper
Communication Type
Corded
Interfaces
GFS4520: USB (micro-USB connector)
Supply Voltage
5 VDC +/-5%
Power Consumption
Operating (Typical): < 225 mA Standby/Idle
Automatic Object Sense Mode: 115 mA
Online & Serial OnLine Modes: 55 mA
Drop Specification
Withstands repeated drops from 1.5m onto concrete surface
Tolerates random vibration, 5 G, from 22 Hz to 300 Hz, 2 hours / 3 axes
Environmental Sealing
IP54
ESD Protection
+/- 16 kV air discharge
Operating Environment
-20° ~ 50°C, Relative Humidity 5 - 95% none condensing
Storage Environment
-40° ~ 70°C, Relative Humidity 5 - 95% none condensing
EMC/Safety Standards
Complies to EU RoHS & China RoHS
Illuminator Exempt group, Aiming Risk Group 1 according to IEC 62471
External Dimensions (WxDxH)
Scanner only : 55 x 48 x 28mm
Weight
52g
