Specifications
Printing Method
Line thermal dot printing
Dot Pitch
8 × 8 dots / mm (203 dpi)
Printing Speed (Max.)
Max. 200 mm/sec
Number of Columns
On 112mm paper up to 69 digits (12 x 24 font A)
On 112mm paper up to 104 digits (8 x 16 font C)
On 112mm paper up to 92 digits (9 x 17 font B)
Character Size
Font A:1.50 ×3.00 mm (12 x 24 Dots)
Font B:1.13 ×3.00 mm (9 x 24 Dots)
Font C: 1.00 x 2.00 mm (8 x 16 Dots)
Character Table/Code Pages
Alphanumeric
International characters
Kana
Kanji (JIS level 1, level 2)
Katakana
Thai code18
WPC1252
437, 850, 852, 857, 858, 860, 863, 864, 865, 866
15 codepages, 17 country tables
Bar-code Type
UPC-A, UPC-E, EAN-13 (JAN-13), EAN-8(JAN-8), Codabar, ITF, CODE39, CODE128, CODABAR(NW-7), CODE93, PDF 417, QR Code, GS1-Databar, Composit Symb, Code3of9
Line Spacing
4.23mm (1/6 inch) (changeable using commands)
Paper feed method
Friction
Paper Type
Thermal Paper Roll
Paper Width
58 - 112 mm (min to max)
Paper Roll Diameter
Paper roll: Max Ø 102.0 mm
Paper Thickness
65 to 150 µm (min to Max)
Paper Supply Method
Easy Paper Loading, Drop in and Print
Auto Cutter
Guillotine, Partial cut or Full cut
Indicators/Controls
Power Light & Error Light
Buzzer
Print Buffer
4K bytes / 45 bytes
NV Memory
384 Kb (capable of storing user-defined characters and logos)
Sensors
Black mark sensor (Photo interrupter)
Paper near end Sensor
Label gap sensor
Drawer Port
1 port (opens 2 drawers, special cable is needed to open 2 drawers)
Interfaces
USB on-board
Optional:
Bluetooth with Apple™ MFi compatibility
Serial (RS-232C compliant)
Compact Wireless LAN
Ethernet
USB with hub
Driver available
Windows Drivers, OPOS Drivers, JAVAPOS Driver, POS for .net Driver, CUPS Driver for Linux/Mac OSX
Software Utilities
Utility software to customize print speed, darkness and to set up user font, logo, maintenance counter, etc.
Power Supply
Rated input: AC 100 to 240 V, 50/60 Hz, 150 VA
Rated output: DC24 V, 2.0 A
Power Consumption
Approx. 70 W (normal printing), 3W (standby)
External Dimensions (WxDxH)
170 x 216 x 151mm
Operating Environment
5 to 40°C, 35 to 90% RH (No condensation)
Storage Environment
-20 to 60°C, 10 to 90% RH (No condensation)
Reliability
Print head life: 100 km, 1 × 108 pulses (At normal temperature/humidity with recommended paper used)
Auto cutter life:1 million cuts (At normal temperature/humidity with recommended paper used)
EMC/Safety Standards
UL, C-UL, FCC Class A, TÜV-GS, CE Marking, C-Tick
