AOPEN DSD-32 HA Digital Media Monitor

(Product may vary from image. Rely only on description for purchasing decisions.)

The DSD-32HA is a 32" LED LCD Monitor specially designed for Digital signage, high brightness with narrow bezel. Very well suited for Electronic Menu boards and high visibility in-store advertising

Private Products

Warranty specified is Back to Base (BTB) warranty Goodson Imports P/L.
Warranty commencement date is date of hardware Invoice.
Warranty covers Manufacturers Faulty Workmanship
Warranty excludes:

  • Power supply
  • Interface and Power Cables
  • Consumable products
  • Options
  • Software and Data Recovery
36 months
  • 32" LED LCD Monitor
  • Metal Cabinet
  • Extra Wide Viewing angle
  • Narrow Bezel
  • Fanless
  • Thermal Alarm & Protection
  • RS232 remote control API utility support
  • Remote Controller
  • High Brightness
  • Industrial grade
  • HDMI & VGA input
NameSizeDownload
No Downloads

Products available to purchase

 SKUVendorName
AODE35-2032X AOPENDE35-HD Digital Engine 2 GB with Xpe
AODSD32-HA AOPENDSD32 HA 32" LCD Monitor
CAB-HDM1m GOODSON1mtr Premium High Speed HDMI Cable
CAB-HDM2m GOODSON2mtr Premium High Speed HDMI Cable
ATTH-3060-UF ATDEC3060 Wall mount Ultra Slim

All Vendor Sku's for this Products

This product is equivalent to the following products

SKUDescription
No Products to Display

Parts documents

Parts layout details

Specifications
Display
32" LED Backlit LCD Display
Aspect Ratio: 16:9
Display Orientation
Portrait or Landscape
Resolution
1920 x 1080
Viewing Area
N/A
Contrast Ratio
4000:1
Brightness
450 nits
Response time
N/A
View Angle
N/A
Tilt Angle
N/A
Touch Panel
N/A
I/O Ports
Audio out x 1
Input Signal
HDMI x 2
VGA x 2
Audio
Connector for 8W x 2 External Speakers
OS Support
N/A
Environmental Sealing
N/A
Operating Environment
0 ~ +40 °C, 10 ~ 80% RH
Storage Environment
-20 ~ +60 °C, 10 ~ 80% RH
Power Supply
AC 100~240V 50/60Hz
Power Consumption
Max. 110W
at Standby Max. 1.5W
External Dimensions (WxDxH)
723mm x 52mm x 417mm
Bezel Width 10.5 mm
Weight
10 Kg
EMC/Safety Standards
C-Tick, CE, FCC, CB, BSMI. RoHS
